CAT6A FTP Plug 90 Degree
77.00EGP 99.00EGP
CAT6A FTP Plug 90 Degree, Tool Free - Gold-Plate:50u" - 0.53*0.32*0.23
1-RJ45/8P8C plugs are designed for termination of solid (single-core) and stranded (patch cord) cables in production of patch cords and in some cases while laying communication lines, for connecting CCTV cameras, etc.
2-Self-clamping Field Tool less Plugs are designed specifically for use with high-speed cables and provide first-class transmission characteristics.
3- Connectors can be used to stack server hardware, workstations, connect various specialized industrial equipment and CCTV cameras.
4-(Cat.6A) connector is made in cast, fully shielded zinc-aluminum alloy housings.
5-They consist of a central insert with RJ45 plug and PCB with IDC, the body divided into two halves and a plastic shank for cable fixation.
6-The cable shield is earthed to the spring-loaded contact in the rear of the housing, providing full electrical contact and further clamped by the shank to securely fix the cable behind the sheath.
7-The supported thickness of the outer shell is 6-8 mm.
8-Connectors design makes it easy to plug the cables without any specialized tools.
9-Only diagonal cutters are needed to gently bite off excess wires.
10- Supplied individually, in an individual polyethylene bag with perforation – similar to switching modules.
